300L SUS304 Stainless Steel Split Solar Water Heater with Aluminium Alloy Heat Pipe Solar Collector
Advantages
New manifold,more stronger.
The frame can be adjusted.
Easy installation.
Tail stock support is made of stainless steel or aluminum alloy.
Working principle
The collector absorbs solar energy and transmits it to the water tank through circulation.
When the temperature of the collector reaches the set value, the controller starts the
circulation pump automatically.
Location
Collector maybe installed either on the roof or wall while water tank may be installed
at any place in a villa flexible .collector harmonizes with villa’s outlook and maintains
villa’s outlook beauty.
| Specification |
| Solar heat storage tank diameter(mm) | 420/460/470/480 |
| Thickness,insulated(mm) | 50/60 |
| Vent connection(inch) | 1/2 |
| Electric heater connection(inch) | 47 |
| Water connection(inch) | 1/2 or 3/4 |
| Frame angle(degree) | 23/25/30/45 |
| Feature: |
| 1. Super anti-erode outer tank:Outer tank is made by stainless steel 304or PVDF. Best anti-erode material,Especial for the seaside area,such as East South Asia,Mexico etc. |
| 2. Feeding water automatic:with special design,feeding water automatic,and ensure the outlet water as stable temperature. |
| 3. We design to install the the solar PV panel supplying the lighting and the cell phone charger. |
| Material: |
| 1. Inner tank:stainless steel SUS304 |
| 2. Vacuum tube:QB-AL-N/AL-47*1500/58*1800 |
| 3. Outer tank:stainless steel SUS304/SUS316/PVDF color steel |
| 4. Frame:coated galvanized steel -1.5mm;Aliminum alloy steel2.0mm |
| 5. The material of insulation:polyurethane50/60mm |
| 6. The reflector:aluminum component;AL 99.85% surface oxidation;stainless steel |
Packing
Evacuated Tube Solar Water Heater: standard export package.
The samples are loaded into the plywood boxes.
Our Services
We defines an OEM (Original Equipment Manufacturer) as an entity or organization that integrates a customized or embedded the product in its own unique solution for sale to its customers.
The proof of this concept is that the product must be significantly transformed.
The OEM Partner primarily uses its own company logo and brand name on its solution and it markets, sells and provides technical and warranty support directly to its customers.
FAQ
Payment terms: T/T, L/C, Paypal, Western union all support.
Delivery time: Sample order 3 working days, Container order 10 working days.
Minimum order quantity: 1 PC
Guarantee period: 8 years
OEM service: Support (Print logo on carton for free)
Notice
1) The angle of the frame can be changed in production according to the local latitude condition of the customers. We can design the suitable angle for the customers
2) We offer the spare accessories and tubes for your order for free
3) We can offer the standing frame for SFB if the customers need
4) We can change the quantity of tubes of each SFB solar collector according to customers' request
5) We can change the different material of manifold according to the requirement of customers , SFB with standing frame.
